• Unique Feature
  Superb Productivity
  - PCIe Gen5 (Graphics, M.2)
  - Dual Channel DDR5
  Rock-Solid Durability
  - 16+2+1 Power Phase, 80A Dr.MOS for VCore+SOC+MISC with Enlarged Heatsink Armor
  - Flexible Integrated I/O Shield
  - 20K Long-lasting Black Caps (high quality and conductive polymer capacitors) for VCore
  Ultrafast Connectivity
  - 5G LAN, 802.11be Wi-Fi 7 Module
  - ASRock Lightning Gaming Ports
  EZ Update
  - BIOS Flashback Button
  - ASRock Auto Driver Installer
  EZ Troubleshooter
  - ASRock Post Status Checker
• CPU
  - Supports AMD Socket AM5 Ryzen™ 9000, 8000 and 7000 Series Processors*



  * The availability of expansion slots may vary by CPU. Please refer to PCIe/M.2 Bandwidth Table for details.
• Chipset
  - AMD X870
• Memory
  - Dual Channel DDR5 Memory Technology
  - 4 x DDR5 DIMM Slots
  - Supports DDR5 ECC/non-ECC, un-buffered memory up to 8000+(OC)*
  - Max. capacity of system memory: 256GB
  - Supports Extreme Memory Profile (XMP) and EXTended Profiles for Overclocking (EXPO) memory modules*



  *Please refer to Memory Support List on ASRock's website for more information.
• BIOS
  - 256Mb AMI UEFI Legal BIOS with GUI support
• Graphics
  Integrated AMD RDNA™ graphics (Actual support may vary by CPU)
  - 1 x HDMI 2.1 TMDS/FRL 8G Compatible, supports HDR, HDCP 2.3 and max. resolution up to 4K 120Hz
  - 2 x USB4, support HDCP 2.3 and max. resolution up to 8K 30Hz** Only the CPU's embedded graphics can be displayed through USB4 ports. If you want to display to a Type-C monitor, please use AM5 Ryzen™ 9000, 8000 and 7000 processors with embedded graphics.* USB4 controller(for USB4_TC1 and USB4_TC2) will run at Gen4x2 with with 8000 (Phoenix 2) series processors.



  *
• Audio
  - 7.1 CH HD Audio with Content Protection (Realtek ALC4082 Audio Codec)
  - Individual PCB Layers for R/L Audio Channel
  - Nahimic Audio
• LAN
  - 5 Gigabit LAN 10/100/1000/2500/5000 Mb/s
  - Realtek RTL8126
• Wireless LAN
  - 802.11be 2x2 Wi-Fi 7 Module
  - Supports IEEE 802.11a/b/g/n/ac/ax/be
  - Supports 2.4GHz/5GHz/6GHz* frequency band
  - Supports 160MHz channel bandwidth with 6GHz* frequency band
  - 1 antenna to support 2 (Transmit) x 2 (Receive) diversity technology
  - Supports Bluetooth 5.4
  - Supports MU-MIMO



  * The Wi-Fi 7 module is supported by Microsoft Windows^® 11 only. There is no driver available for Windows^® 10. The availability of the 6GHz band will depend on the different regulation status of each country and region. It will be activated (for supported countries) through Windows^® Update and software updates once available.
• Slots
  CPU:
  - 1 x PCIe 5.0 x16 Slot (PCIE1), supports x16 mode*
  Chipset:
  - 2 x PCIe 3.0 x16 Slots (PCIE2 and PCIE3), support x4 mode*
  - 1 x M.2 Socket (Key E), supports type 2230 WiFi/BT PCIe WiFi module
  - 15μ Gold Contact in VGA PCIe Slot (PCIE1)



  * PCIE1 will run at Gen5x16 with 9000 and 7000 series processors, Gen4x8 with 8000 (Phoenix 1) series processors and Gen4x4 with 8000 (Phoenix 2) series processors.
  If M2_3 is occupied, PCIE2 will downgrade to x2 mode.
  If M2_4 is occupied, PCIE3 will downgrade to x2 mode.
  Supports NVMe SSD as boot disks
• Storage
  CPU:
  - 1 x Blazing M.2 Socket (M2_1, Key M), supports type 2280 PCIe Gen5x4 (128 Gb/s) mode*
  - 1 x Blazing M.2 Socket (M2_2, Key M), supports type 2280 PCIe Gen5x4 (128 Gb/s) mode*
  Chipset:
  - 1 x Hyper M.2 Socket (M2_3, Key M), supports type 2280 PCIe Gen4x4 (64 Gb/s) mode*
  - 1 x Hyper M.2 Socket (M2_4, Key M), supports type 2230/2242/2260/2280 PCIe Gen4x4 (64 Gb/s) mode*
  - 2 x SATA3 6.0 Gb/s Connectors



  * Supports NVMe SSD as boot disks
  M2_1 is the first priority for M.2 installation.
  M2_1 will run at Gen5x4 with 9000 and 7000 series processors and Gen4x4 with 8000 (Phoenix 1 and Phoenix 2) series processors.
  M2_2 will run at Gen5x4 with 9000 and 7000 series processors and Gen4x4 with 8000 (Phoenix 1) series processors. M2_2 will be unavailable with 8000 (Phoenix 2) series processors.
  If M2_2 is occupied, both rear USB4 Type-C Ports and M2_2 will downgrade to x2 mode. You can switch M2_2 to x4 mode in BIOS setting, but doing so will disable USB4_TC1 and USB4_TC2.
  If M2_3 is occupied, PCIE2 will downgrade to x2 mode.
  If M2_4 is occupied, PCIE3 will downgrade to x2 mode.
• RAID
  - Supports RAID 0 and RAID 1 for SATA storage devices
  - Supports RAID 0, RAID 1 and RAID 10 for M.2 NVMe storage devices
• USB
  CPU:
  - 2 x USB4 Type-C (Rear)
  - 2 x USB 3.2 Gen1 Type-A (Rear (USB32_1 and USB32_4))
  Chipset:
  - 1 x USB 3.2 Gen2x2 Type-C (Front)
  - 9 x USB 3.2 Gen1 Type-A (5 Rear (USB32_2, USB32_356, USB32_7), 4 Front))
  - 1 x USB 3.2 Gen1 Type-C (Rear)
  - 10 x USB 2.0 (6 Rear, 4 Front)



  * All USB ports support ESD Protection
• Connector
  - 1 x SPI TPM Header
  - 1 x Thermistor Cable Header
  - 1 x Power LED and Speaker Header
  - 1 x RGB LED Header*
  - 3 x Addressable LED Headers**
  - 2 x CPU Fan Connectors (4-pin) (Smart Fan Speed Control)***
  - 3 x Chassis Fan Connectors (4-pin) (Smart Fan Speed Control)***
  - 1 x AIO Pump Fan Connector (4-pin) (Smart Fan Speed Control)***
  - 1 x 24 pin ATX Power Connector (Hi-Density Power Connector)
  - 2 x 8 pin 12V Power Connectors (Hi-Density Power Connector)
  - 1 x Front Panel Audio Connector
  - 2 x USB 2.0 Headers (Support 4 USB 2.0 ports)
  - 2 x USB 3.2 Gen1 Headers (Support 4 USB 3.2 Gen1 ports)
  - 1 x Front Panel Type C USB 3.2 Gen2x2 Header (20 Gb/s)



  * Supports in total up to 12V/3A, 36W LED Strip
  ** Support in total up to 5V/3A, 15W LED Strip
  *** CPU_FAN1 supports the fan power up to 1A (12W).
  CPU_FAN2, CHA_FAN1~3 and AIO_PUMP support the fan power up to 3A (36W).
  CPU_FAN2, CHA_FAN1~3 and AIO_PUMP can auto detect if 3-pin or 4-pin fan is in use.
• Rear Panel I/O
  - 2 x Antenna Ports
  - 1 x HDMI Port
  - 1 x Optical SPDIF Out Port
  - 2 x USB4 Type-C Ports (40 Gb/s)*
  - 1 x USB 3.2 Gen1 Type-C Port
  - 7 x USB 3.2 Gen1 Type-A Ports (USB32_34 are Lightning Gaming Ports. USB32_56 support Ultra USB Power.)**
  - 6 x USB 2.0 Ports
  - 1 x RJ-45 LAN Port
  - 1 x BIOS Flashback Button
  - 1 x Line Out Jack (Gold Audio Jack)
  - 1 x Microphone Input Jack (Gold Audio Jack)



  * Supports USB PD 3.0 up to 5V@3A (15W) charging
  USB4 controller (for USB4_TC1 and USB4_TC2) will run at Gen4x2 with with 8000 (Phoenix 2) series processors.
  If M2_2 is occupied, both rear USB4 Type-C Ports and M2_2 will downgrade to x2 mode. You can switch M2_2 to x4 mode in BIOS setting, but doing so will disable USB4_TC1 and USB4_TC2.

  ** Device exceeds USB 3.2 Type-A power rating of 5V@0.9A (4.5W) may trigger over-current protection (OCP), will require system reboot to restore USB power.
• Software and UEFI
  Software
  - ASRock Motherboard Utility (A-Tuning)
  - ASRock Polychrome SYNC*
  UEFI
  - ASRock EZ Mode
  - ASRock Full HD UEFI
  - ASRock Auto Driver Installer
  - ASRock Instant Flash



  *These utilities can be downloaded from ASRock Live Update & APP Shop.
• Accessories
  - 2 x SATA Data Cables
  - 2 x ASRock WiFi 2.4/5/6 GHz Antennas
  - 1 x Thermistor Cable
• Form Factor
  - ATX Form Factor: 12.0-in x 9.6-in, 30.5 cm x 24.4 cm
  - 8 Layer PCB
• OS
  - Microsoft Windows^® 10 64-bit / 11 64-bit
• Certifications
  - FCC, CE
  - ErP/EuP ready (ErP/EuP ready power supply is required)
  - CEC Tier II ready

Link:https://www.asrock.com/mb/AMD/X870%20LiveMixer%20WiFi/index.asp#Specification

• Unique Feature
  Rock-Solid Durability
  - 3+1+1 Power Phase
  EZ Update
  - ASRock Auto Driver Installer
• CPU
  - Supports 14^th, 13^th & 12^th Gen Intel^® Core™ Processors (LGA1700)
  - Supports Intel^® Hybrid Technology
  - Supports Intel^® Turbo Boost Max 3.0 Technology
• Chipset
  - Intel^® H610
• Memory
  - Dual Channel DDR4 Memory Technology
  - 2 x DDR4 DIMM Slots
  - Supports DDR4 non-ECC, un-buffered memory up to 3200
  - Supports ECC UDIMM memory modules (operate in non-ECC mode)
  - Max. capacity of system memory: 64GB
  - Supports Intel^® Extreme Memory Profile (XMP) 2.0
• BIOS
  - 128Mb AMI UEFI Legal BIOS with GUI support
• Graphics
  - Intel^® Xe Graphics Architecture (Gen 12)
  - 2 x HDMI 2.1 TMDS Compatible, support HDCP 2.3 and max. resolution up to 4K 60Hz



  * Intel^® UHD Graphics Built-in Visuals and the VGA outputs can be supported only with processors which are GPU integrated.
• Audio
  - 7.1 CH HD Audio (Realtek ALC897 Audio Codec)
• LAN
  - Gigabit LAN 10/100/1000 Mb/s
  - Realtek 8111H
• Slots
  CPU:
  - 1 x PCIe 4.0 x16 Slot (PCIE1), supports x16 mode*
  Chipset:
  - 1 x PCIe 3.0 x1 Slot (PCIE2)*



  * Supports NVMe SSD as boot disks
• Storage
  Chipset:
  - 1 x Ultra M.2 Socket (M2_1, Key M), supports type 2242/2260/2280 PCIe Gen3x4 (32 Gb/s) mode*
  - 4 x SATA3 6.0 Gb/s Connectors



  * Supports NVMe SSD as boot disks
• USB
  - 4 x USB 3.2 Gen1 Type-A (2 Rear, 2 Front)
  - 6 x USB 2.0 (4 Rear, 2 Front)



  * All USB ports support ESD Protection
• Connector
  - 1 x SPI TPM Header
  - 1 x Chassis Intrusion and Speaker Header
  - 1 x CPU Fan Connector (4-pin)*
  - 1 x Chassis/Water Pump Fan Connector (4-pin) (Smart Fan Speed Control)**
  - 1 x 24 pin ATX Power Connector
  - 1 x 8 pin 12V Power Connector
  - 1 x Front Panel Audio Connector
  - 1 x USB 2.0 Header (Supports 2 USB 2.0 ports)
  - 1 x USB 3.2 Gen1 Header (Supports 2 USB 3.2 Gen1 ports)



  * CPU_FAN1 supports the fan power up to 1A (12W).
  ** CHA_FAN1/WP supports the fan power up to 2A (24W).
  CHA_FAN1/WP can auto detect if 3-pin or 4-pin fan is in use.
• Rear Panel I/O
  - 1 x PS/2 Mouse/Keyboard Port
  - 2 x HDMI Ports
  - 2 x USB 3.2 Gen1 Type-A Ports
  - 4 x USB 2.0 Ports
  - 1 x RJ-45 LAN Port
  - HD Audio Jacks: Line in / Front Speaker / Microphone
• Software and UEFI
  Software
  - ASRock Motherboard Utility (A-Tuning)
  UEFI
  - ASRock EZ Mode
  - ASRock Full HD UEFI
  - ASRock My Favorites in UEFI
  - ASRock Auto Driver Installer
  - ASRock Instant Flash



  *These utilities can be downloaded from ASRock Live Update & APP Shop.
• Accessories
  - 1 x I/O Shield
  - 2 x SATA Data Cables
  - 1 x Screw for M.2 Socket
• Form Factor
  - Micro ATX Form Factor: 8.66-in x 7.6-in, 22.0 cm x 19.3 cm
• OS
  - Microsoft Windows^® 10 64-bit / 11 64-bit
• Certifications
  - FCC, CE
  - ErP/EuP ready (ErP/EuP ready power supply is required)

Link proizvodjaca: https://www.asrock.com/MB/Intel/H610M-H2M.2/index.asp#Specification

• Vrhunska produktivnost
  - PCIe Gen5 (grafika, M.2)
  - Dvokanalni DDR5
  - USB4 Type-C portovi (40 Gb/s)
  Solidna izdržljivost
  - 14+2+1 faza napajanja, 80A Dr.MOS za VCore+SOC+ MISC sa uvećanim oklopom hladnjaka
  - Fleksibilni integrisani I/O štit
  Ultrabrzo povezivanje
  - 2.5G LAN, 802.11be Wi-Fi 7 modul
  EZ ažuriranje
  - BIOS Flashback dugme
  - ASRock Auto Driver Installer
  EZ Troubleshooter
  - ASRock Post Status Checker
• CPU
  - Podržava AMD Socket AM5 Ryzen™ procesore serije 9000, 8000 i 7000 *



  * Dostupnost slotova za proširenje može varirati u zavisnosti od CPU-a. Za detalje pogledajte tabelu propusnog opsega PCIe/M.2 .
• Čipset
  - AMD X870
• Memorija
  - Dvokanalna DDR5 memorijska tehnologija
  - 4 x DDR5 DIMM slota
  - Podržava DDR5 ECC/ne-ECC, memoriju bez bafera do 8000+(OC) *
  - Maks. kapacitet sistemske memorije: 256 GB
  - Podržava Extreme Memory Profile (XMP) i EXTended profile za overclocking (EXPO) memorijske module



  * Molimo pogledajte listu podrške za memoriju na ASRock-ovoj web stranici za više informacija.
• BIOS
  - 256Mb AMI UEFI Legal BIOS sa podrškom za GUI
• Grafika
  Integrisana AMD RDNA™ grafika (stvarna podrška može varirati u zavisnosti od procesora)
  - 1 x HDMI 2.1 TMDS/FRL 8G kompatibilan, podržava HDR, HDCP 2.3 i max. rezolucija do 4K 120Hz
  - 2 x USB4, podrška HDCP 2.3 i max. rezolucija do 8K 30Hz *



  * Samo grafika ugrađena u CPU može se prikazati preko USB4 portova. Ako želite da prikazujete na Type-C monitoru, koristite AM5 Ryzen™ 9000, 8000 i 7000 procesore sa ugrađenom grafikom.
• Audio
  - 7.1 CH HD audio sa zaštitom sadržaja (Realtek ALC1220 audio kodek)
  - Senzor impedance na stražnjem izlaznom portu
  - Pojedinačni slojevi PCB-a za R/L audio kanal
  - Nahimic Audio
• LAN
  - 2.5 Gigabit LAN 10/100/1000/2500 Mb/s
  - Dragon RTL8125BG
  - Podržava Dragon 2.5G LAN softver
  - Smart Auto Adjust Bandwidth Control
  - Vizuelno korisničko korisničko sučelje
  - Vizuelna statistika korištenja mreže
  - Optimizirana zadana postavka za igre, pretraživač, Režimi strujanja
  - korisnički prilagođena kontrola prioriteta
• Bežični LAN
  - 802.11be 2x2 Wi-Fi 7 modul
  - Podržava IEEE 802.11a/b/g/n/ac/ax/axe/be
  - Podržava 2,4GHz/5GHz/6GHz * frekvencijski opseg
  - Podržava propusni opseg kanala od 160MHz sa 6GHz * frekvencijski opseg
  - 1 antena za podršku 2 (prijenos) x 2 (prijem) tehnologije diverziteta
  - Podržava Bluetooth 5.4
  - Podržava MU-MIMO



  * Wi-Fi 7 (opseg 6 GHz) će biti podržan od strane Microsoft Windows ^® 11. Dostupnost će zavisiti od različitog statusa propisa u svakoj zemlji i regionu. Aktiviraće se (za podržane zemlje) putem Windows® ^Update i ažuriranja softvera kada budu dostupna.
• Slots
  CPU:
  - 1 x PCIe 5.0 x16 slot (PCIE1), podržava x16 režim *
  Čipset:
  - 1 x PCIe 4.0 x16 slot (PCIE2), podržava x4 režim *
  - 1 x M.2 utičnica (Key E), podržava tip 2230 WiFi /BT PCIe WiFi modul
  - Podržava AMD CrossFire™
  - 15μ zlatni kontakt u VGA PCIe slotu (PCIE1)



  * PCIE1 će raditi na Gen5x16 sa procesorima serije 9000 i 7000, Gen4x8 sa procesorima serije 8000 (Phoenix 1) i Gen4x4 sa procesorima serije 8000 (Phoenix 2).
  Ako je M2_2 zauzet, PCIE2 će biti onemogućen.
  Podržava NVMe SSD kao diskove za pokretanje
• Skladištenje
  CPU:
  - 1 x Blazing M.2 socket (M2_1, ključ M), podržava tip 2280 PCIe Gen5x4 (128 Gb/s) mod * Čipset:
  - 1 x Hyper M.2 socket (M2_2, ključ M), podržava tip 2230 /2242/2260/2280 PCIe Gen4x4 (64 Gb/s) način *
  - 1 x Ultra M.2 socket (M2_3, ključ M), podržava tip 2280 SATA3 6.0 Gb/s & PCIe Gen3x4 (32 Gb/s) modove *
  - 2 x SATA3 6,0 Gb/s konektora ASMedia ASM1061:
  - 2 x SATA3 6,0 Gb/s konektora



  * Podržava NVMe SSD kao diskove za pokretanje
  M2_1 je prvi prioritet za M.2 instalaciju.
  M2_1 će raditi na Gen5x4 sa 9000 i 7000 serija procesora i Gen4x4 sa 8000 (Phoenix 1 i Phoenix 2) serijom procesora.
  Ako je M2_2 zauzet, PCIE2 će biti onemogućen.
  Ako je SATA3_1 ili SATA3_2 zauzet, M2_3 će se vratiti na Gen3x2 način rada.
• RAID
  - Podržava RAID 0 i RAID 1 za SATA uređaje za skladištenje
  - Podržava RAID 0, RAID 1 i RAID 10 za M.2 NVMe uređaje za skladištenje *



  * Potrebne su dodatne M.2 NVMe kartice za proširenje za podršku RAID 10
• USB
  CPU:
  - 2 x USB4 Type-C (stražnji)
  - 2 x USB 3.2 Gen1 Type-A (stražnji (USB32_1 i USB32_2))
  Čipset:
  - 1 x USB 3.2 Gen2x2 Type-C (prednji)
  - 4 x USB 3.2 Gen1 Tip -A (2 stražnja (USB32_3 i USB32_4), 2 prednja)
  - 9 x USB 2.0 (6 stražnja, 3 prednja)



  * Svi USB portovi podržavaju ESD zaštitu
• Konektor
  - 1 x utičnica za termistorski kabel
  - 1 x LED dioda za napajanje i zaglavlje zvučnika
  - 1 x RGB LED utičnica *
  - 3 x adresabilna LED utičnica * *
  - 2 x konektori za CPU ventilator (4-pinski) (Pametna kontrola brzine ventilatora) * * *
  - 4 x konektori za ventilator na kućištu (4-pinski) (pametna kontrola brzine ventilatora) * * *
  - 1 x konektor za ventilator za AIO pumpu (4-pinski) (Pametna kontrola brzine ventilatora) * * *
  - 1 x 24-pinski ATX konektor za napajanje
  - 2 x 8 pinski 12V konektor za napajanje (konektor za napajanje visoke gustine)
  - 1 x audio konektor na prednjoj ploči
  - 2 x USB 2.0 zaglavlja (podržava 3 USB 2.0) portovi)
  - 1 x USB 3.2 Gen1 zaglavlje (podržava 2 USB 3.2 Gen1 porta)
  - 1 x prednji panel Tip C USB 3.2 Gen2x2 Header (20 Gb/s)



  * Podržava ukupno do 12V/3A, 36W LED traku
  * * Podrška ukupno do 5V/3A, 15W LED traku
  * * * CPU_FAN1 podržava snagu ventilatora do 1A (12W).
  CPU_FAN2, CHA_FAN1~4 i AIO_PUMP podržavaju snagu ventilatora do 3A (36W).
  CPU_FAN2, CHA_FAN1~4 i AIO_PUMP mogu automatski otkriti da li se koristi 3-pinski ili 4-pinski ventilator.
• I/O stražnje ploče
  - 2 x priključka za antenu
  - 1 x HDMI priključak
  - 1 x optički SPDIF izlaz
  - 2 x USB4 Type-C porta (40 Gb/s) *
  - 4 x USB 3.2 Gen1 Type-A porta
  - 6 x USB 2.0 portova
  - 1 x RJ-45 LAN port
  - 1 x BIOS Flashback dugme
  - 1 x linijski izlaz (zlatni audio priključak)
  - 1 x ulaz za mikrofon Jack (zlatni audio priključak)



  * Podržava USB PD 3.0 do 5V@3A (15W) punjenje
• Softver i UEFI
  Softver
  - ASRock Uslužni program za matičnu ploču (A-Tuning)
  - ASRock Dragon 2.5G LAN softver
  - ASRock Polychrome SYNC *
  UEFI
  - ASRock EZ Mode
  - ASRock Full HD UEFI
  - ASRock Auto Driver Installer
  - ASRock Instant Flash



  * Ovi uslužni programi se mogu preuzeti sa ASRock Live Update & APP Shop-a.
• Pribor
  - 2 x SATA podatkovna kabla
  - 2 x ASRock WiFi 2.4/5/6 GHz antene
• Form Factor
  - ATX Form Faktor: 12,0 in x 9,6 in, 30,5 cm x 24,4 cm
  - 8 Layer PCB
• OS
  - Microsoft Windows® ¹⁰ 64-bitni / 11 64-bitni
• Certifikati
  - FCC, CE
  - ErP/EuP spremno (potrebno je napajanje spremno za ErP/EuP)

• Unique Feature
  Superb Productivity
  - PCIe Gen5 (Graphics, M.2)
  - Dual Channel DDR5
  - USB4 Type-C Ports (40 Gb/s)
  Rock-Solid Durability
  - Server-Grade Low-Loss PCB
  - 24+2+1 Power Phase, 110A SPS for VCore+SOC with Enlarged Heatsink Armor
  - Flexible Integrated I/O Shield
  - 20K Long-lasting Black Caps (high quality and conductive polymer capacitors)
  Ultrafast Connectivity
  - 5G LAN, 802.11be Wi-Fi 7 Module
  - ASRock Lightning Gaming Ports
  EZ Update
  - BIOS Flashback Button
  - ASRock Auto Driver Installer
• CPU
  - Supports AMD Socket AM5 Ryzen™ 9000, 8000 and 7000 Series Processors*
  - Supports ASRock Hyper BCLK Engine



  *The availability of expansion slots may vary by CPU. Please refer to PCIe/M.2 Bandwidth Table for details.
• Chipset
  - AMD X870E
• Memory
  - Dual Channel DDR5 Memory Technology
  - 4 x DDR5 DIMM Slots
  - Supports DDR5 ECC/non-ECC, un-buffered memory up to 8200+(OC)*
  - Max. capacity of system memory: 256GB
  - Supports Extreme Memory Profile (XMP) and EXTended Profiles for Overclocking (EXPO) memory modules*



  *Please refer to Memory Support List on ASRock's website for more information.
• BIOS
  - 256Mb AMI UEFI Legal BIOS with GUI support
• Graphics
  Integrated AMD RDNA™ graphics (Actual support may vary by CPU)
  - 1 x HDMI 2.1 TMDS/FRL 8G Compatible, supports HDR, HDCP 2.3 and max. resolution up to 4K 120Hz
  - 2 x USB4, support HDCP 2.3 and max. resolution up to 8K 30Hz*



  * Only the CPU's embedded graphics can be displayed through USB4 ports. If you want to display to a Type-C monitor, please use AM5 Ryzen™ 9000, 8000 and 7000 processors with embedded graphics.
• Audio
  - 5.1 CH HD Audio with Content Protection (Realtek ALC4082 Audio Codec)
  - WIMA Audio Capacitors (For Rear Outputs)
  - ESS SABRE9219 DAC for Rear Panel Audio (130dB SNR)
  - Individual PCB Layers for R/L Audio Channel
  - Direct Drive Technology on Front headphone port (Supports up to 600 Ohm headsets)
  - Nahimic Audio
• LAN
  - 5 Gigabit LAN 10/100/1000/2500/5000 Mb/s
  - Realtek RTL8126
• Wireless LAN
  - 802.11be 2x2 Wi-Fi 7 Module
  - Supports IEEE 802.11a/b/g/n/ac/ax/axe/be
  - Supports 2.4GHz/5GHz/6GHz* frequency band
  - Supports 160MHz channel bandwidth with 6GHz* frequency band
  - 1 antenna to support 2 (Transmit) x 2 (Receive) diversity technology
  - Supports Bluetooth 5.4
  - Supports MU-MIMO



  *The Wi-Fi 7 module is supported by Microsoft Windows^® 11 only. There is no driver available for Windows^® 10. The availability of the 6GHz band will depend on the different regulation status of each country and region. It will be activated (for supported countries) through Windows^® Update and software updates once available.
• Slots
  CPU:
  - 2 x PCIe 5.0 x16 Slots (PCIE1 and PCIE2), support x16 or x8/x8 modes*
  Chipset:
  - 1 x Vertical M.2 Socket (Key E), supports type 2230 WiFi/BT PCIe WiFi module
  - Supports AMD CrossFire™



  *PCIE1 will run at Gen5x16 with 9000 and 7000 series processors, Gen4x8 with 8000 (Phoenix 1) series processors and Gen4x4 with 8000 (Phoenix 2) series processors.
  Supports NVMe SSD as boot disks
• Storage
  CPU:
  - 1 x Blazing M.2 Socket (M2_1, Key M), supports type 2280 PCIe Gen5x4 (128 Gb/s) mode*
  Chipset:
  - 1 x Hyper M.2 Socket (M2_2, Key M), supports type 2280 PCIe Gen4x4 (64 Gb/s) mode*
  - 1 x Hyper M.2 Socket (M2_3, Key M), supports type 2280 PCIe Gen4x4 (64 Gb/s) mode*
  - 1 x Hyper M.2 Socket (M2_4, Key M), supports type 2280 PCIe Gen4x4 (64 Gb/s) mode*
  - 6 x SATA3 6.0 Gb/s Connectors



  * Supports NVMe SSD as boot disks
  M2_1 is the first priority for M.2 installation.
  M2_1 will run at Gen5x4 with 9000 and 7000 series processors and Gen4x4 with 8000 (Phoenix 1 and Phoenix 2) series processors.
• RAID
  - Supports RAID 0, RAID 1 and RAID 10 for SATA storage devices
  - Supports RAID 0, RAID 1 and RAID 10 for M.2 NVMe storage devices
• USB
  CPU:
  - 2 x USB4 Type-C (Rear)
  - 2 x USB 3.2 Gen2 Type-A (Rear)
  Chipset:
  - 1 x USB 3.2 Gen2x2 Type-C (Front)
  - 3 x USB 3.2 Gen2 Type-A (Rear)
  - 7 x USB 3.2 Gen1 Type-A (3 Rear, 4 Front)
  - 6 x USB 2.0 (2 Rear, 4 Front)



  * All USB ports support ESD Protection
• Connector
  - 3 x Thermistor Cable Headers
  - 1 x Power LED and Speaker Header
  - 1 x RGB LED Header*
  - 3 x Addressable LED Headers**
  - 2 x CPU Fan Connector (4-pin) (Smart Fan Speed Control)***
  - 4 x Chassis Fan Connectors (4-pin) (Smart Fan Speed Control)***
  - 1 x AIO Pump Fan Connector (4-pin) (Smart Fan Speed Control)***
  - 1 x Water Pump Fan Connector (4-pin) (Smart Fan Speed Control)***
  - 1 x 24 pin ATX Power Connector (Hi-Density Power Connector)
  - 2 x 8 pin 12V Power Connectors (Hi-Density Power Connector)
  - 1 x Front Panel Audio Connector (15μ Gold Audio Connector)
  - 2 x USB 2.0 Headers (Support 4 USB 2.0 ports)
  - 2 x USB 3.2 Gen1 Headers (Support 4 USB 3.2 Gen1 ports)
  - 1 x Front Panel Type C USB 3.2 Gen2x2 Header (20 Gb/s)
  - 1 x Dr. Debug with LED
  - 1 x Power Button with LED
  - 1 x Reset Button with LED



  * Supports in total up to 12V/3A, 36W LED Strip
  ** Support in total up to 5V/3A, 15W LED Strip
  *** CPU_FAN1 supports the fan power up to 1A (12W).
  CPU_FAN2, CHA_FAN1~4, AIO_PUMP and W_PUMP support the fan power up to 3A (36W).
  CPU_FAN2, CHA_FAN1~4, AIO_PUMP and W_PUMP can auto detect if 3-pin or 4-pin fan is in use.
• Rear Panel I/O
  - 2 x Antenna Ports
  - 1 x HDMI Port
  - 1 x Optical SPDIF Out Port
  - 2 x USB4 Type-C Ports (40 Gb/s)*
  - 5 x USB 3.2 Gen2 Type-A Ports (10 Gb/s) (USB32_12 are Lightning Gaming Ports.)
  - 3 x USB 3.2 Gen1 Type-A Ports (USB32_34 supports Ultra USB Power.)
  - 2 x USB 2.0 Ports
  - 1 x RJ-45 LAN Port
  - 1 x Clear CMOS Button
  - 1 x BIOS Flashback Button
  - 1 x Line Out Jack (Gold Audio Jack)
  - 1 x Microphone Input Jack (Gold Audio Jack)



  * Supports USB PD 3.0 up to 5V@3A (15W) charging
• Software and UEFI
  Software
  - ASRock Motherboard Utility (A-Tuning)
  - ASRock Polychrome SYNC*
  UEFI
  - ASRock EZ Mode
  - ASRock Full HD UEFI
  - ASRock Auto Driver Installer
  - ASRock Instant Flash



  *These utilities can be downloaded from ASRock Live Update & APP Shop.
• Accessories
  - 4 x SATA Data Cables
  - 1 x ASRock WiFi 2.4/5/6 GHz Antenna
  - 1 x ARGB Splitter Cable
  - 3 x Thermistor Cables
• Form Factor
  - EATX Form Factor: 12.0-in x 10.5-in, 30.5 cm x 26.7 cm
  - 8 Layer PCB
  - 2oz Copper PCB
• OS
  - Microsoft Windows^® 10 64-bit / 11 64-bit
